Smart Switch Aqara Shutter Switch H2 EU (DS-K02D/DS-K02E), for Shutters, Thread/Zigbee, Matter, White

The Aqara Shutter Switch H2 EU is a smart wall switch for controlling roller shutters and blinds. It lets you open, close or stop shutters remotely and set their exact position as a percentage, with smart or custom calibration. It works over Thread (Matter) or Zigbee and also has Bluetooth, so it fits into Aqara Home and Matter-compatible ecosystems. The extra buttons can be configured as wireless buttons to trigger scenes. The switch features an LED indicator, power monitoring, overload protection and power-off memory. It runs on 100–250V AC, 50/60Hz with a maximum load of 8A. The module follows the standard 55 mm size and works with frames such as Gira System 55 and Merten M. It measures 86 x 86 x 45 mm and is white. A hub is required for operation.

Product Description :

• Brand: Aqara
• Model: Shutter Switch H2 EU
• Model Number: DS-K02D/DS-K02E
• Product Type: Smart shutter switch
• Wireless Protocols: Thread, Zigbee, Bluetooth
• Matter: Yes (over Thread)
• Thread / Zigbee Frequency: 2405–2480 MHz
• Bluetooth Frequency: 2402–2480 MHz
• Max Output Power: ≤13 dBm
• Power Input: 100–250V AC, 50/60Hz
• Maximum Load: 8A
• Features: Position control, calibration, configurable wireless buttons, LED indicator, power monitoring, overload protection, power-off memory
• Frame Compatibility: 55 mm (Gira System 55, Merten M)
• Application: Aqara Home
• Requires Hub: Yes
• Operating Temperature: -10°C – 40°C
• Operating Humidity: 0–95% RH, non-condensing
• Dimensions: 86 x 86 x 45 mm
• Color: White
